Artikelnummer: 3980992

NEC OPS Slot-in PC - Digital signage player - Intel Celeron - RAM 4 GB - vaste schijf 64 GB - Windows 7 Embedded - zwart

OPS Slot-In PCs make digital signage simpler and more flexible without additional cables or devices

The full line-up of OPS Slot-in PCs supports a wide variety of applications starting from static content playback and ranging to the most demanding interactive, high resolution or resource hungry applications. The 6th generation Intel® processors (Skylake) deliver a new class of computing to power the next generation of slot-in computing. The OPS concept provides a compact and fully embedded solution ensuring that all connectors are integrated including power, video & audio signals and RS-232. All NEC large format displays (except E series 32" to 65"), PX and PH installation projectors feature this option slot.

Delivering Genuine Benefits

- Powerful possibilities - the 6th generation Intel® processors deliver a new class of computing with a host of new features to power the next generation of embedded computing.
- Intel® HD graphics - provides Ultra HD resolution, intense detail and faster frame rates, giving you a remarkable visual experience.
- Industrial grade components - secure high reliability whilst withstanding extreme operating conditions.
- Seamless and fully embedded - as all connectors are inside the display including power, video, audio signals and RS-232, no external cables are required.
- High usage flexibility - thanks to wide connectivity such as 3 x USB, DisplayPort out, Gigabit ethernet and audio.
- Upgrade the power of your displays at any time - savings are possible by upgrading only your OPS device or your display with no need to change all hardware.
- A commitment to quality - tailored warranties available to best match long-term demands by extending standard warranty up to 5 years.
- Economical - enjoy more performance whilst consuming less power.

Processor

• Frequentie van processor: 2,4 GHz
• Processorfamilie: Intel® Celeron® G
• Processormodel: G3900E
• Aantal processorkernen: 2
• Processor socket: BGA 1440
• Processor cache: 2 MB
• Processor cache type: Smart Cache
• Systeembus: 8 GT/s
• Processor aantal threads: 2
• PCI Express slots versie: 3.0
• Processor lithografie: 14 nm
• Processor operating modes: 64-bit
• Stepping: R0
• Bus type: DMI3
• Codenaam processor: Skylake
• Thermal Design Power (TDP): 35 W
• Processorserie: Intel Celeron Processor G3000 Series for Desktop
• Maximaal aantal PCI Express-lijnen: 16
• PCI Express configuraties: 1x16,1x8+2x4,2x8
• Tjunction: 100 °C
• Maximaal intern geheugen ondersteund door processor: 64 GB
• Conflictvrije processor: Ja
• Geheugentypen ondersteund door processor: DDR3L-SDRAM,DDR4-SDRAM
• Klokgeheugen-snelheden ondersteund door processor: 1333,1600,1866,2133 MHz
• Geheugenbandbreedte ondersteund door de processor ( max): 34,1 GB/s
• Geheugenkanalen ondersteund door processor: Dual
• ECC ondersteund door processor: Ja
• Voltage geheugen ondersteund door processor: 1,35 V

Geheugen

• Intern geheugen: 4 GB
• Intern geheugentype: DDR4-SDRAM
• Maximum intern geheugen: 16 GB
• Geheugenslots: 2x SO-DIMM
• Kloksnelheid geheugen: 2133 MHz
• ECC: Ja

Poorten & interfaces

• Aantal poorten USB 3.0 (3.1 Gen 1) Type A: 3
• Aantal Ethernet LAN (RJ-45)-poorten: 1
• DVI-poort: Nee
• Aantal DisplayPorts: 1
• Hoofdtelefoonuitgangen: 1
• Microfoon, line-in ingang: Ja

Gewicht en omvang

• Breedte: 200 mm
• Diepte: 120 mm
• Hoogte: 30 mm
• Gewicht: 900 g
• Breedte verpakking: 260 mm
• Diepte verpakking: 190 mm
• Hoogte verpakking: 70 mm
• Gewicht verpakking: 1 kg

Energie

• Typisch stroomverbruik: 35 W

Eisen aan de omgeving

• Temperatuur, in bedrijf: 0 - 40 °C
• Relatieve luchtvochtigheid, in bedrijf: 0 - 90 procent

Netwerk

• Wi-Fi: Nee
• Bekabelingstechnologie: 10/100/1000Base-T(X)
• Ethernet LAN, data-overdrachtsnelheden: 10,100,1000 Mbit/s
• Wake-on-LAN: Ja

Opslagmedia

• Totale opslagcapaciteit: 64 GB
• Opslagmedia: SSD
• Geïntegreerde geheugenkaartlezer: Nee
• SSD interfaces: M.2
• SSD capaciteit: 64 GB

Certificaten

• Certificering: CE, FCC

Software

• Inclusief besturingssysteem: Windows Embedded Standard 7

Grafisch

• Ingebouwde grafische adapter: Ja
• On-board graphics adapter model: Intel® HD Graphics 510
• Familie ingebouwde grafische adapter: Intel® HD Graphics
• Maximaal geheugen ingebouwde grafische adapter: 64 GB
• Basisfrequentie ingebouwde grafische adapter: 350 MHz
• Graphics on-board -adapter dynamische frequentie (max): 950 MHz
• On-board grafische adapter DirectX-versie: 12.0
• On-board grafische adapter OpenGL versie: 4.4
• On-board grafische adapter ID: 0x1902
• Discreet grafische adapter model: Niet beschikbaar
• Aantal displays ondersteund (door on-board grafische adapter): 3

Processor speciale functies

• Ondersteunde instructie sets: SSE4.1,SSE4.2
• Processorcode: SR2GH
• Intel® vPro™ Technology: Nee
• Intel® Hyper Threading Technology (Intel® HT Technology): Nee
• Intel® Turbo Boost Technology: Nee
• Intel® Quick Sync Video Technology: Ja
• Intel® InTru™ 3D Technology: Ja
• Intel® Wireless Display (Intel® WiDi): Ja
• Intel® Clear Video HD Technology (Intel® CVT HD): Ja
• Intel® Insider™: Ja
• Intel® AES New Instructions (Intel® AES-NI): Ja
• Enhanced Intel SpeedStep Technology: Ja
• Execute Disable Bit: Ja
• Idle States: Ja
• Thermal Monitoring Technologies: Ja
• Intel® Trusted Execution Technology: Nee
• Schaalbaarheid: 1S
• Intel® Enhanced Halt State: Ja
• Intel® Clear Video Technology for Mobile Internet Devices (Intel® CVT for MID): Ja
• Intel® VT-x with Extended Page Tables (EPT): Ja
• Ingebouwde opties beschikbaar: Ja
• Graphics & IMC lithografie: 14 nm
• Intel® Small Business Advantage (Intel® SBA): Nee
• Intel® TSX-NI: Nee
• Intel® Secure Key: Ja
• Intel® 64: Ja
• Intel® Stable Image Platform Program (SIPP): Nee
• Intel® OS Guard: Nee
• Intel® Virtualization Technology for Directed I/O (VT-d): Ja
• Intel® Clear Video-technologie: Ja
• Intel® Software Guard Extensions (Intel® SGX): Ja
• Intel® Virtualization Technology (VT-x): Ja
• Verpakkingsgrootte processor: 42 x 28 mm
• ARK ID processor: 90713

Prestatie

• Chipset moederbord: Intel® HM170
• Kleur van het product: Zwart

€ 741,18
