Artikelnummer: 4370529
NEC OPS Slot-in PC - Model A - digital signage player - Intel Core i3 - RAM 4 GB - vaste schijf 64 GB - Windows 10 IOT - zwart
OPS Slot-In PCs make digital signage simpler and more flexible without additional cables or devices
The full line-up of OPS Slot-in PCs supports a wide variety of applications starting from static content playback and ranging to the most demanding interactive, high resolution or resource hungry applications. The 6th generation Intel® processors (Skylake) deliver a new class of computing to power the next generation of slot-in computing. The OPS concept provides a compact and fully embedded solution ensuring that all connectors are integrated including power, video & audio signals and RS-232. All NEC large format displays (except E series 32" to 65"), PX and PH installation projectors feature this option slot
- Powerful possibilities - the 6th generation Intel® processors deliver a new class of computing with a host of new features to power the next generation of embedded computing
- Intel® HD graphics - provides Ultra HD resolution, intense detail and faster frame rates, giving you a remarkable visual experience
- Industrial grade components - secure high reliability whilst withstanding extreme operating conditions
- Seamless and fully embedded - as all connectors are inside the display including power, video, audio signals and RS-232, no external cables are required
- High usage flexibility - thanks to wide connectivity such as 3 x USB, DisplayPort out, Gigabit ethernet and audio
- Upgrade the power of your displays at any time - savings are possible by upgrading only your OPS device or your display with no need to change all hardware
- A commitment to quality - tailored warranties available to best match long-term demands by extending standard warranty up to 5 years
- Economical - enjoy more performance whilst consuming less power
Processor
- Frequentie van processor: 2,7 GHz
- Processorfamilie: Zesde generatie Intel® Core™ i3
- Processormodel: i3-6100E
- Aantal processorkernen: 2
- Processor socket: BGA 1440
- Processor cache: 3 MB
- Processor cache type: Smart Cache
- Systeembus: 8 GT/s
- Processor aantal threads: 4
- Processor lithografie: 14 nm
- Thermal Design Power (TDP): 35 W
Geheugen
- Intern geheugen: 4 GB
- Intern geheugentype: DDR4-SDRAM
- Maximum intern geheugen: 16 GB
- Geheugenlayout: 2 x 2 GB
- Geheugenslots: 2x SO-DIMM
Poorten & interfaces
- Aantal poorten USB 3.0 (3.1 Gen 1) Type A: 3
- Aantal Ethernet LAN (RJ-45)-poorten: 1
- Aantal DisplayPorts: 1
- Hoofdtelefoonuitgangen: 1
- Microfoon, line-in ingang: Ja
- RS‐232/422-poort: Ja
Gewicht en omvang
- Breedte: 200 mm
- Diepte: 120 mm
- Hoogte: 30 mm
- Gewicht: 900 g
- Breedte verpakking: 260 mm
- Diepte verpakking: 190 mm
- Hoogte verpakking: 70 mm
- Gewicht verpakking: 1 kg
Energie
- Typisch stroomverbruik: 41 W
Eisen aan de omgeving
- Temperatuur, in bedrijf: 0 - 40 °C
- Relatieve luchtvochtigheid, in bedrijf: 0 - 90 procent
Netwerk
- Wi-Fi: Nee
- Bekabelingstechnologie: 10/100/1000Base-T(X)
- Ethernet LAN, data-overdrachtsnelheden: 10,100,1000 Mbit/s
- Wake-on-LAN: Ja
Opslagmedia
- Totale opslagcapaciteit: 64 GB
- Opslagmedia: SSD
- Aantal storage drives geïnstalleerd: 1
- SSD capaciteit: 64 GB
Certificaten
- Certificering: CE, FCC class A
Software
- Inclusief besturingssysteem: Microsoft Windows 10 IoT Enterprise
Inhoud van de verpakking
- Gebruikershandleiding: Ja
Grafisch
- Ingebouwde grafische adapter: Ja
- On-board graphics adapter model: Intel® HD Graphics 530
- Aparte grafische adapter: Nee
- Maximaal geheugen ingebouwde grafische adapter: 64 GB
- Basisfrequentie ingebouwde grafische adapter: 350 MHz
- Graphics on-board -adapter dynamische frequentie (max): 950 MHz
- On-board grafische adapter DirectX-versie: 12.0
- On-board grafische adapter OpenGL versie: 4.4
- Aantal displays ondersteund (door on-board grafische adapter): 3
Prestatie
- Chipset moederbord: Intel® HM170
- Grootte BIOS-geheugen: 128 Mbit
- Kleur van het product: Zwart
- BIOS type: AMI
- Audiochip: Realtek ALC887
€ 1.009,41
