Artikelnummer: 3971699
Gigabyte GeForce GTX 1070 Mini ITX OC - Grafische kaart - GF GTX 1070 - 8 GB GDDR5 - PCIe 3.0 x16 - 2 x DVI, HDMI, DisplayPort
GIGABYTE Custom-designed Cooling System
The GIGABYTE Custom-designed cooling system features a 90mm fan, 3 pure copper composite heat-pipes, unique blade fan design, heat pipes direct touch technology together delivering an effective heat dissipation capacity for higher performance at lower temperatures.
Unique Blade Fan Design
The airflow is spilt by the triangle fan edge, and guided smoothly through the 3D stripe curve on the fan surface, effectively enhancing the air flow by 23% over traditional fans.
3D Active Fan
The semi-passive fans will remain off when the GPU is under a set loading or temperature for low power gaming. It allows gamers to enjoy gameplay in complete silence when the system is running light or idle.
Composite heat-pipes
The composite heat-pipes combines both thermal conductivity and phase transition for efficiently managing the transfer of heat between two solid interfaces which increases 29% of cooling capacity.
Heat Pipe Direct Touch
The pure copper heat pipes are shaped to maximize the direct contact area to the GPU.
One-click Super overclocking
With a simple click on XTREME engine utility, gamers can easily tune the card to meet their various gaming requirements without any overclocking knowledge, while saving the hassle of manual adjustment.
Ultra Durable Materials
Engineered with the highest-grade chokes and capacitors, this graphic card delivers outstanding performance and durable system lifespan.
Built for OverClocking with 5+1 power phases
Compared to founders edition, the 5+1 power phases on the card make the MOSFET working at a lower temperature and provide more stable voltage output. (*founders edition:4+1)
Xtreme Engine
Adjust clock speeds, voltage, fan performance, power target, OSD setting can be monitored and tuned in real-time according to your own preference through this intuitive interface.
Processor
- Grafische processor familie: NVIDIA
- Grafische processor: GeForce GTX 1070
- Maximum resolutie: 7680 x 4320 Pixels
- CUDA: Ja
- Frequentie van processor: 1556 MHz
- Ondersteuning voor parallel processing: 2-Way SLI
- FireStream: Nee
- Processor boost clock speed: 1746 MHz
- Resolutie (maximum digitaal): 7680 x 4320 Pixels
- CUDA cores: 1920
Geheugen
- Grafische geheugen: 8 GB
- Grafische adapter, soort geheugen: GDDR5
- Geheugenbus: 256 Bit
- Kloksnelheid geheugen: 8008 MHz
Minimale systeemeisen
- Ondersteunt Windows: Ja
- Ondersteunt Linux: Ja
Poorten & interfaces
- Soort aansluiting: PCI Express x16 3.0
- Aantal HDMI-poorten: 1
- DVI-D poorten: 2
- Aantal DisplayPorts: 1
- HDMI versie: 2.0b
- DisplayPort versie: 1.4
Gewicht en omvang
- Diepte: 37 mm
- Hoogte: 131 mm
- Breedte: 169 mm
Energie
- Minimum system power voorraad: 500 W
- Extra geleverde power connectors: 1x 8-pin
Design
- Type koeling: Actief
- Vormfactor: ATX/ITX
- Aantal sloten: 2
- Kleur van het product: Zwart, Oranje
Prestatie
- Geïntegreerde TV Tuner: Nee
- PhysX: Ja
- DirectX versie: 12.0
- Shader model versie: 5.0
- OpenGL versie: 4.5
- HDCP: Ja
- Dual Link DVI: Ja
- Volledige HD: Ja
- NVIDIA GameWorks VR: Ja
- NVIDIA G-SYNC: Ja
€ 387,91
