Artikelnummer: 4593187
Lenovo ThinkSystem SR650 7X06 - Server - rack-uitvoering - 2U - 2-weg - 1 x Xeon Gold 6134 / 3.2 GHz - RAM 32 GB - SAS - hot-swap (verwisselbaar zonder uitschakelen) 2.5" - geen HDD - Matrox G200 - geen OS - monitor: geen - TopSeller
Lenovo ThinkSystem SR650 is an ideal 2-socket 2U rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The SR650 server is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), enterprise applications, collaboration/email, and business analytics and big data.
Featuring the Intel Xeon Processor Scalable Family, the SR650 server offers scalable performance, storage capacity, and I/O expansion. The SR650 server supports up to two processors, up to 3 TB of 2666 MHz TruDDR4 memory, up to 24x 2.5-inch or 14x 3.5-inch drive bays with an extensive choice of NVMe PCIe SSDs, SAS/SATA SSDs, and SAS/SATA HDDs, and flexible I/O expansion options with the LOM slot, the dedicated storage controller slot, and up to 6x PCIe slots.
Combining performance and flexibility, the SR650 server is a great choice for small and medium businesses up to the large enterprise. It can provide outstanding uptime to keep business-critical applications and cloud deployments running safely. Ease of use and comprehensive systems management tools help make deployment easier. Outstanding reliability, availability, and serviceability (RAS) and high-efficiency design improve your business environment and help save operational costs.
The SR650 server offers basic or advanced hardware RAID protection and a wide range of networking options, including selectable LOM, ML2, and PCIe network adapters. The next-generation Lenovo XClarity Controller, which is built into the SR650 server, provides advanced service processor control, monitoring, and alerting functions.
Processor
- Frequentie van processor: 3,2 GHz
- Processorfamilie: Intel® Xeon®
- Processormodel: 6134
- Aantal processorkernen: 8
- Aantal geïnstalleerde processoren: 1
- Processor cache type: L3
- Processor cache: 24,75 MB
- Processor socket: LGA 3647
- Chipset moederbord: Intel® C624
- Maximale turbofrequentie van processor: 3,7 GHz
- Processor lithografie: 14 nm
- Processor aantal threads: 16
- Processor operating modes: 64-bit
- Stepping: H0
- Bus type: UPI
- aantal QPI links: 3
- Codenaam processor: Skylake
- Tcase: 79 °C
- Maximaal intern geheugen ondersteund door processor: 768 GB
- Geheugentypen ondersteund door processor: DDR4-SDRAM
- Klokgeheugen-snelheden ondersteund door processor: 2666 MHz
- Geheugenkanalen ondersteund door processor: Hepta
- ECC ondersteund door processor: Ja
- Execute Disable Bit: Ja
- Maximaal aantal PCI Express-lijnen: 48
- Verpakkingsgrootte processor: 76 x 56.5 mm
- Ondersteunde instructie sets: AVX,AVX 2.0,AVX-512,SSE4.2
- Processorcode: SR3AR
- Schaalbaarheid: S4S
- Ingebouwde opties beschikbaar: Nee
- Thermal Design Power (TDP): 130 W
- Conflictvrije processor: Ja
Geheugen
- Intern geheugen: 32 GB
- Intern geheugentype: DDR4-SDRAM
- Geheugenslots: 24
- ECC: Ja
- Kloksnelheid geheugen: 2666 MHz
- Geheugenlayout: 1 x 32 GB
Beeldscherm
- Ingebouwd display: Nee
Poorten & interfaces
- Aantal USB 2.0-poorten: 1
- VGA (D-Sub)poort(en): 1
- Seriële poort(en): 1
- Aantal poorten USB 3.0 (3.1 Gen 1) Type A: 3
Gewicht en omvang
- Breedte: 445 mm
- Diepte: 720 mm
- Hoogte: 87 mm
Energie
- Redundante voeding: Ja
- Netvoeding: 750 W
- Aantal ondersteunde redundante voedingen: 2
- Aantal geïnstalleerde redundante voedingen: 1
- Voeding, frequentie ingang: 50/60 Hz
Eisen aan de omgeving
- Temperatuur, in bedrijf: 5 - 45 °C
- Temperatuur bij opslag: -40 - 60 °C
- Relatieve luchtvochtigheid, in bedrijf: 8 - 90 procent
- Luchtvochtigheid bij opslag: 8 - 90 procent
- Hoogte, in bedrijf: 0 - 3050 m
Netwerk
- Ethernet LAN: Ja
- Wi-Fi: Nee
- Bluetooth: Nee
- Bekabelingstechnologie: 10/100/1000Base-T(X)
Opslagmedia
- RAID support: Ja
- Soorten RAID: 0, 1, 5, 6, 10, 50, 60, JBOD
- Ondersteunde RAID-controllers: 1x 930-8i
- Ondersteunde HDD-groottes: 2.5"
- Hot-swap: Ja
- Ondersteunde opslagstationinterfaces: SAS, SATA III
- Geïntegreerde geheugenkaartlezer: Nee
Certificaten
- Energy Star-certificaat: Ja
Software
- Compatibele besturingssystemen: Microsoft Windows Server 2016\nMicrosoft Windows Server 2012 R2\nRed Hat Enterprise Linux 7.4\nRed Hat Enterprise Linux 7.3\nRed Hat Enterprise Linux 6.9 Server x64 Edition\nSUSE Linux Enterprise Server 12 SP3\nSUSE Linux Enterprise Server 12 SP2\nSUSE Linux Enterprise Server 11 for AMD64/EM64TSP4\nVMware vSphere 6.5 (ESXi) Update 1\nVMware vSphere 6.5 (ESXi)\nVMware vSphere 6.0 (ESXi) Update 3
Uitbreidingsmodules
- PCI Express x8 slots: 2
- PCI Express slots versie: 3.0
Design
- Type behuizing: Rack (2U)
- Soort optische drive: Nee
- Rack-montage: Ja
- Overtollige fans ondersteuning: Ja
- Rekrails: Ja
Grafisch
- Aparte grafische adapter: Nee
- Ingebouwde grafische adapter: Ja
- On-board graphics adapter model: Matrox G200
Processor speciale functies
- Enhanced Intel SpeedStep Technology: Ja
- Intel® Virtualization Technology for Directed I/O (VT-d): Ja
- Intel® Hyper Threading Technology (Intel® HT Technology): Ja
- Intel® Turbo Boost Technology: 2.0
- Intel® vPro™ Technology: Ja
- Intel® AES New Instructions (Intel® AES-NI): Ja
- Intel® Trusted Execution Technology: Ja
- Intel® VT-x with Extended Page Tables (EPT): Ja
- Intel® TSX-NI: Ja
- Intel® 64: Ja
- Intel® Virtualization Technology (VT-x): Ja
- ARK ID processor: 120493
Prestatie
- Prestatiebeheer: XClarity Enterprise
- Trusted Platform Module (TPM): Ja
€ 5.251,55
