Artikelnummer: 4510229
Lenovo ThinkServer TS150 70UB - Server - towermodel - 4U - 1-wegs - 1 x Xeon E3-1225V6 / 3.3 GHz - RAM 8 GB - HDD 2 x 1 TB - DVD-brander - HD Graphics P630 - GigE - geen OS - monitor: geen - TopSeller
Powerful, Yet Affordable
The Lenovo ThinkServer TS150 is the perfect first server for small and medium businesses, remote or branch offices, and retail environments. It uses the latest technologies to provide enterprise-class power. Intel® Xeon® E3-1200 v5 Series processors incorporate up to four cores, integrated graphics, and support for 64GB of 2133MHz DDR4 memory. These features enable you to run larger workloads up to 20% faster than before, and even virtual machines (VMs) for more efficient server usage. Intel Active Management Technology (AMT) built into the TS150 offers easy-to-use, industry-standard management tools for remote monitoring, updates, and repairs. The TS150 provides much higher performance than a premium desktop can offer for about the same price.
Flexible Value
In addition to powerful Intel® Xeon® E3 processors, the TS150 offers a choice of Core® i3, Pentium®, and Celeron® processors for those on a smaller budget. Flexible storage options include 5.25-inch optical/tape drives, 3.5-inch HDDs, and 2.5-inch HDDs/SSDs. Up to 24TB of internal enterprise-class storage supports storage-intense workloads—such as office applications, web, e-mail and file/print serving—and provides growth capacity. Integrated software RAID 0/1/10/5—upgradable to entry hardware RAID—and Error Correcting Code (ECC) memory offer increased uptime. Multiple server operating systems are supported; client OS support enables retail/Point of Sale applications.
Environment-Friendly
The TS150 saves you money and helps the environment with energy-efficient processors and 1.2V DDR4 memory, 80 PLUS Bronze (up to 85% efficient) or Platinum (92%) power supplies, and 65% recyclable materials. The office-friendly chassis is small (25L/4U), whisper-quiet (26dB) and fits under or beside a desk.
Processor
- Frequentie van processor: 3,3 GHz
- Processorfamilie: Intel® Xeon® E3 familie
- Processormodel: E3-1225V6
- Aantal processorkernen: 4
- Aantal geïnstalleerde processoren: 1
Geheugen
- Intern geheugen: 16 GB
- Intern geheugentype: DDR4-SDRAM
- Maximum intern geheugen: 64 GB
- Geheugenslots: 4 x DIMM
- ECC: Ja
- Kloksnelheid geheugen: 2400 MHz
- Geheugenlayout: 1 x 8 GB
Poorten & interfaces
- VGA (D-Sub)poort(en): 1
- Aantal Ethernet LAN (RJ-45)-poorten: 1
- Seriële poort(en): 1
- Aantal poorten USB 3.0 (3.1 Gen 1) Type A: 8
- Aantal DisplayPorts: 1
Gewicht en omvang
- Breedte: 175 mm
- Diepte: 431 mm
- Hoogte: 375 mm
- Gewicht: 12,5 kg
Energie
- Redundante voeding: Nee
- Netvoeding: 250 W
- Aantal hoofdvoedingen: 1
Eisen aan de omgeving
- Temperatuur, in bedrijf: 10 - 35 °C
- Temperatuur bij opslag: -40 - 60 °C
- Relatieve luchtvochtigheid, in bedrijf: 8 - 80 procent
- Luchtvochtigheid bij opslag: 10 - 90 procent
- Hoogte, in bedrijf: 0 - 3048 m
Netwerk
- Ethernet LAN: Ja
- Bekabelingstechnologie: 10/100/1000Base-T(X)
- Ethernet interface type: Gigabit Ethernet
Opslagmedia
- Totale opslagcapaciteit: 2000 GB
- Het aantal geïnstalleerde HDD's: 2
- HDD omvang: 3.5"
- HDD interface: SATA III
- RAID support: Ja
- HDD rotatiesnelheid: 7200 RPM
- HDD capaciteit: 1000 GB
- Soorten RAID: 0, 1, 5, 10
- Maximum aantal HDD's per behuizing: 4
- Ondersteunde HDD-groottes: 3.5"
Software
- Inclusief besturingssysteem: Nee
- Compatibele besturingssystemen: Microsoft Windows Server 2012 R2/2012\nWindows MultiPoint Server 2012\nWindows 10 Pro\nRed Hat Enterprise Linux 6.7/7.2\nSUSE Linux Enterprise Server 11/12\nVMware vSphere (ESXi) 5.5U3/6.0U2
Design
- Type behuizing: Rack (4U)
- Soort optische drive: DVD±RW
Grafisch
- Ingebouwde grafische adapter: Ja
- On-board graphics adapter model: Intel® HD Graphics P630
Prestatie
- Geluidsniveau: 35 dB
- BIOS type: UEFI
- Trusted Platform Module (TPM): Ja
- Trusted Platform Module (TPM) version: 1.2
€ 927,84
